MATERIAL ROLL RACK LS-5

MATERIAL ROLL RACK LS-5

Material roll rack LS-5 is designed for five rolls.

Key features:

- Universal roll racks designed for fabric roll storage or feeding.
- Frame made of closed steel profiles and powder-coated tubes.
- Tubes equipped with special cones that can be blocked to fix the roll.
- Tubes are placed in special slots between wheels on bearings.
- Special brake system to prevent self-unwinding of the fabric rolls.
- Non-standard roll racks are available on request.

Specifications:

Model:    LS-5
Maximum roll width:    1800 mm (70.86")
Maximum roll diameter:    400 mm (15.74")
Maximum roll weight:    30 kg (66.13 lbs)
Maximum roll quantity:    5
Roll brake system :    Yes
Wheels: Yes
